           Over 35 Years of High Quality Steel Drafting




          Company Profile


          JCM & Associates Limited is a Canadian structural and miscellaneous steel drafting business that is committed to providing the highest quality detailing services around.  At JCM we take steel drafting very seriously.  We are not finished until our customers are completely happy.  Our excellent service combined with our overall knowledge of the steel business is what makes us stand out from our competitors.


          We offer complete and comprehensive drafting services and more!  Working closely with the fabricator, we follow the project from beginning to end.  All drawings and correspondence is done to suit the fabricators standards and needs.


          Our mission is to further enhance the structural steel industry by providing customers with top quality shop and erection drawings.


          Although we are based in Canada, the majority of our projects are located in the North Eastern United States.  No job is too big or too small.  Whether a complex new build or an intricate renovation, we love the individual challenges that each project brings.


          Column

          Two persons icon

          Our top of the line coordination and project management skills allow us to work along side the fabricator, GC and other trades to seamlessly complete projects.

          Column

          Graph icon

          Using SDS/2 we are able to provide complete 3D steel models for BIM purposes!


          Column

          Line graph with ascending arrow icon

          We provide top quality shop and erection drawings for both the structural steel on the job as well as any miscellaneous steel required!
